The company's main luggage rubber fabricproduct series include: nitrile rubber fabric, natural styrene butadiene rubber fabric, neoprene rubber fabric, hepalon rubber fabric, etc. The products are widely used in sports backpacks, luggage materials, shoes, tents, sofas, fitness equipment, handbags, storage bags, clothing, inflatable boats, aprons, oil storage bags and other fields. The color and crafts of various products can be customized according to customer requirements. Common patterns include twill, carbon fiber pattern, finest cloth pattern, linen pattern, 3*3 pattern, 621-3 pattern, etc. The thickness series of luggage tape is 0.65, 0.8, 1.0, 1.2, etc.



Hypalon adhesive rubber fabric：

Rubber fabric Technical Specifications
Basefabric: Nylon cloth,translation 420
Coating outside: Chlorosulfonated polyethylene (CSM)
For the underCoating: Chlorosulfonated polyethylene (CSM)



Parameter Table:

Item	Method	Unit	TO.65 Specifcations	TO.8 Specifcations	T1.0 Specifcations
Weight	ISO2286	g/㎡	800±80	1000±100	1300±130
Thickness	IS02286	mm	0.65±0.1	0.8±0.1	1.0±0.1
Tear strength	IS04674-1	N	Warp 60, Weft 60	Warp 60, Weft 60	Warp 60, Weft 60
Peeling Test Adhesion	IS02411	N/5cm	Warp 100, Weft 100	Warp 100, Weft 100	Warp 100, Weft 100
Tensile strength	IS01421	N/5cm	Warp 2000, Weft 2000	Warp 2000, Weft 2000	Warp 2000, Weft 2000
Stretch	IS01421	(%)	Warp 25, Weft 35	Warp 25, Weft 35	Warp 25, Weft 35
wear and tear	GB/T1689-014	g	0.135
Heat Aging	IS0 142170℃x7day	%	Hold rate≥80
Our company has passed ISO-9001 international standard certification Quality Assurance





Practical application case：
